Philéole Building
The “Tramontana” wind turbine is intended for owners of houses and buildings.
Philéole designed this wind turbine for houses exposed to the wind and not easily connected to electricity networks, high-rise buildings, in town or in the countryside, the roof of harbor master’s offices along the sea or any other building.
The triple mini wind turbine of Philéole
Energy collected from the upper part of the houses throughout the year, the Philéole Triple “Tramontana” wind turbine maintains electricity production and allows batteries to be charged and / or electricity to be returned to the network, either directly or by connection to a photovoltaic installation.
Advantages of the “Tramontana” Wind Turbine
For production of electricity, all year round, in winter as in summer, day and night.
Optimisation of productivity by design: the positioning of the blades in relation to each other ensures that they influence each other to increase the productivity of the whole structure. The deflectors attached to the bottom and top of the structure also improve energy production. For example, 30% more wind is redirected to the blades.
Quiet : Savonius type two-bladed wind turbines have a vertical axis. The peripheral speed at the tip of the blade does not exceed that of the wind, which avoids any whistling.
Lightweight and efficient : the very particular design of the blades and air outlet vents, covered by patent, makes the “Tramontana” propeller light and efficient. Its low weight only results in low tilting torque, even in the raised position.
Strong and resistant : Its design is thick and rigid in the center, more flexible towards the periphery. It reduces centrifugal forces to better cope with turbulent winds. the “Tramontana” has been tested in a wind tunnel up to winds of 25 m / s (90 km / hour, 48 kn) without damage or significant loss of performance.
Safe : the low speed at the tip of the blade and the reduced inertia of the propeller (weight: 4kg) prevent any danger for the user as well as for birds or insects.
Reliable and space-saving : its vertical axis makes electricity production more regular because it is independent of the direction of the wind and vortices. Its small dimensions allow mounting at the top of a roof.
No coupling : 100% of the electricity production is sent through the connection cables
“The little we can do, the very little we can do, we must do”
Théodore Monod
Technical information
The vertical wind turbine is easily placed on the roof, on the top of a fireplace or in a corner of the garden.
the connection to the electrical network is simple and can be coupled with the connection of a photovoltaic installation.
Technical data
Three-bladed wind turbine with vertical axis Philéole
Dimensions of the propellers: diameter 320 mm, height 900 mm, wind section 0.27m2
Overall dimensions: length 1200 mm, width 2000 mm, height 1500 mm
Total weight: 150 kg
Starting from winds of 3 m / s (6kn)
Battery charge current in 19 m / s (37kn) wind: 7 A (100 Watts) for a single wind turbine
Output voltage: 12 Volts (optional 24 or 48 Volts)
Power coefficient max. Cp = 0.21 for winds of 16 m / s (31kn)
